Video How to install CD player on Toyota Sienna
08:57   |   43K+ views   |   08/20/2018 at 23:59


  • it is a mp3 player which I want to
  • install instead standard stage CD player
  • in Toyota in my case it's Toyota Sienna
  • mm I'm going to need a connector this
  • wires for CD player which calls wire
  • harness which usually comes with player
  • I don't know that wiring diagram from
  • internet particularly this player and
  • wiring diagram for Toyota CD player
  • harness papas the recognition I
  • highlighted numbers four speakers and
  • the road car harness colors next to
  • player harness colors according the
  • wiring diagrams
  • I'll just want to show you what I mean
  • so here is a wiring diagram for Pioneer
  • CD player is how I match the colors
  • let's take number 16 for example on
  • Pioneer CD player diagram it stays for
  • red wire it also says connect to
  • terminal controlled by ignition switch
  • so we have to find this switch on the
  • next diagram on the card diagram where
  • it is well then you have to take a look
  • at your car wiring diagram and find what
  • wire color corresponding to ignition
  • switch so just look at this diagram
  • looking with the switch what is and this
  • switch what is is second from top and it
  • says switched and this corresponding
  • color gray so here on CD player wiring
  • diagram I marked gray next to number 16
  • so the red wire which comes from CD
  • player should go to the gray wire of
  • your car player harness
  • let's tie out the wire harness for CD
  • player but this connector is connected
  • directly to your car amplifier standard
  • amplifier which in your car you can see
  • this amplifier here on the bottom and
  • entirely Sienna is behind a middle
  • console pocket so you have to open one
  • to see it the other end of harness
  • equipped this a different connector
  • which goes to standard car CD player 70
  • 80 113 adapter was my mistake to buy it
  • fits physically but it's electrical
  • pinout doesn't match and it didn't work
  • anyway so 70 1761 was a good match and
  • it works the wires color from adapter
  • are not as same as on Toyota wiring
  • diagram
  • but for this adapter you have a wiring
  • diagram on plastic bag which comes with
  • discard nur's you just have to match it
  • is your CD player wiring diagram let's
  • say you match the white wire with black
  • stripe look at schematic number seven is
  • a left front speaker - means negative
  • polarity so this white black wire goes
  • to purple car harness wire here is a
  • purple wire of car harness it connects
  • to white black wire from adapter what
  • black wire is a left front speaker -
  • here is the left front speaker - which
  • is number seven it connects to player
  • white black harness wire and you can
  • verify that it connects to the purple
  • car harness wire so you can avoid
  • mistake the wires colors of the second
  • adapter connector are also on this
  • diagram all you have to do is to twist
  • the wires together and solder connection
  • after that you may apply an electrical
  • tape
  • we need only wires which your car player
  • harness has some wires like a power
  • antenna will be unused - leftover like
  • these three wires on the right you can
  • just wrap them with electrical tape
  • you're going to need to pocket
  • this model 8800 8000 to remove the
  • player just pry out the base off with
  • your hands and pull it in I have
  • detached my player player already but
  • there are four screws which you need to
  • unscrew using ten millimeters torx key
  • so screws located here and then an
  • opposite side here and down them after
  • removing screws you just have to pull
  • out your player there are two connectors
  • on the back you have to disconnect them
  • the color of wires here doesn't match to
  • Toyota wiring diagram so we're not going
  • to use them you can see I have just
  • disconnected the two connectors which
  • were connected to the amplifier you can
  • see the metal box
  • on the bottom here where it is say I'll
  • open this pocket glove compartment
  • middle console so we have to connect
  • these adapters to connectors which you
  • just saw which were connected as I told
  • before to the amplifier and the next
  • connector you have to connect to your CD
  • player you need to detach the brackets
  • from a car CD player
  • there are actually four screws here I
  • have to detach them already you need to
  • match brackets for pocket you can reuse
  • the bolts which were with your standard
  • CD player the screws for player are not
  • metric so use ones which came with your
  • new player the last step is to put it
  • back and connect the player adapter and
  • antenna
  • I have to comment to turn on this player
  • and then put it back screwing the whole
  • poles back and put the bezel back in
  • this case you'll be sure that all your
  • contacts are connected this actually is
  • a factory disk
  • then you can check from them speakers
  • there seems to be working
  • you
  • you

Download subtitle


This video shows how to install MP3 CD Player (Pioneer DEH-3400) in Toyota Sienna. Metra 70-1761 Radio Wiring Harness fits for most Toyota Cars. There are standard procedures when you replace Standard CD Player with another one.
There is also useful information here:
Also, if you got Error 23, when you plug in USB thumb drive it means, that your storage device is not FAT32 formatted. Conversion from NTFS to FAT32 will not solve the problem. You have to reformat your thumb drive to default FAT32 File System. Use any windows OS, right click on thumb drive letter, select Format, in next window select FAT32 (Default), select Quick formatting, click Format. Then simple copy your MP3 files to Thumb drive. It works.
Remote control works with the same principle as for TV. If it does not, replace the battery CR2025. I installed CR2032. Same 3 volts. This is not a precision device, so it won't matter.
